Phrozen Arco FDM 3D Printer
Specifications
Specifications
-
Printing Volume
-
Framework
-
Single / Multi-Color
-
Printing Speed*
-
Maximum Hotend Flow Rate*
-
Maximum Heated Bed Temperature
-
Maximum Nozzle Temperature
-
Printing Power
-
Power Requirement
-
System Type (Firmware)
-
Slicer
-
Display Screen
-
Supported Filament
-
Connectivity
-
Assistance Features
-
Machine Weight
-
Measurements
Industrial Grade Cooling
300×300×300mm³ Large Volume
Versatile Software Compatibility
Aerospace-Grade Alloy
Fast Multi-Color Swapping
One-Piece
Flying Gantry
Removable Protective Enclosure
High-Speed, No Wobble
Breaking Away from Traditional Moving-Bed Designs
Engineered from the Ground Up for Total Stability
Most CoreXY printers move the heated bed during printing, which causes the model to shake. ARCO uses a fixed heated bed that keeps the print steady while its flying gantry lifts the printhead with precision. Like an F1 car accelerating with perfect control, ARCO delivers both speed and stability in every layer.
Arco Reinforces Stability Right from Its Structure
Typical FDM Structure
- Model moves with the bed, causing wobble.
- Unstable center of gravity.
- Large prints often fail.
- Higher risk of layer shifts and stringing.
ARCO’s Optimized Structure
- Model stays firmly in place on the heated bed.
- Low center of gravity for ultra stable printing.
- High success rate, even with large-scale models.
- Lower risk of layer shifting and stringing.
Details Matter. ARCO Delivers Rock-Solid Stability
Solid Build
Full-Body Aerospace Aluminum Frame
ARCO is built with 6000-series aerospace-grade aluminum. Four T-type lead screws and reinforced columns add strength and rigidity for consistent performance at high speeds.
Stable Motion
One-Piece Flying Gantry with XY Linear Rails
An all-metal flying gantry combined with precision XY linear rails ensures smooth travel and precise movement across every axis.
Uniform Heat
4-Layer Heated Bed with Over 90% Heat Uniformity
The bed reaches 100°C in just 2 minutes. With over 90 percent heat distribution, it helps prevent warping and keeps large prints firmly in place from the first layer.
ARCO: Big. Fast. Unstoppable
300×300×300mm³ Large Printing Volum | Max Print Speed: 1,000 mm/s* | Acceleration: Up to 40,000 mm/s² | Max Flow Rate: 50 mm³/s
Keep Up with Your Inspiration — Design It, Print It, Done Fast
Raining? Print New Slippers at Work and Walk Them Home After
Hit Send Before Bed, Wake Up to a Castle — Printed Overnight
Keep Up with Your Inspiration — Design It, Print It, Done Fast
Raining? Print New Slippers at Work and Walk Them Home After
Hit Send Before Bed, Wake Up to a Castle — Printed Overnight
隨時跟上設計靈感，開會完就火速交件
- 300×300×300 mm 大體積列印空間
- 最大列印速度可達 1000 mm/s
- 加速度高達 40000 mm/s
- 最大流量 50 mm³/s
*搭配 CHT高流量噴嘴與普羅森高速PLA， 0.2 mm 層高
雨天上班，下班印好拖鞋直接穿回家
睡前丟檔案，一夜就把城堡蓋好
- 300×300×300 mm 大體積列印空間
- 最大列印速度可達 1000 mm/s
- 加速度高達 40000 mm/s
- 最大流量 50 mm³/s
*搭配 CHT高流量噴嘴與普羅森高速PLA， 0.2 mm 層高
*With CHT® high-flow nozzles and Phrozen high-speed PLA, 0.2 or 0.1 height.
Details Matter. ARCO Delivers Rock-Solid Stability
ARCO is the first to bring patented industrial-grade heat pipe technology to FDM printing. Paired with a huge 18 mm gear, this system cools efficiently and shortens the distance between the extrusion gear and nozzle, delivering stronger torque and higher flow for smoother, clog-free printing.
ARCO DEP Extrusion: High Stability, Maximum Precision
Standard Extrusion
- Longer extrusion path.
- Frequent extrusion issues.
- Smaller gears lead to weaker torque and low flow.
- Quality varies with different materials.
ARCO DEP Extrusion
- Ultra-short extrusion path.
- Smooth and more precise extrusion.
- Larger gears provide stronger torque and higher flow.
- Consistent quality across a wide range of materials.
4-Tube Direct Feed for 50% Faster Color Swaps
Flexible Enclosure for a Quieter, Cleaner Print Environment
ARCO Premium Nozzle Options for Every Print Job
Bondtech CHT®
Tri-Channel Design for High-Speed Printing
Designed by Bondtech, the CHT® nozzle uses a triple-channel molten core to boost melting efficiency. It supports flow rates up to 50 mm³ per second, making it ideal for fast prints and large-scale models.
SE GammaMaster®
Durable Coating with Excellent Heat Transfer
Created by Slice Engineering for ARCO, the GammaMaster® combines a hardened alloy, Low Gamma™ coating, and copper-based core. It offers strong wear resistance and high thermal conductivity, perfect for long jobs and abrasive filaments.
Phrozen Standard
Stable Heat Conduction for Everyday Printing
Perfect for daily use with PLA, PETG, and other common filaments. This nozzle delivers reliable heat transfer and steady performance across your regular print jobs.
Get Started with ARCO. Easy Setup, Zero Hassle
ARCO comes with everything you need to print confidently. From setup to your first finished model, our tools and guides help you get started fast and stay on track.
-
![]()
PIXUP Marketplace
Phrozen’s high-quality, in-house developed 3D model marketplace allows you to download and start printing anytime.
-
![]()
Orca Slicer
ARCO supports Orca Slicer, the open-source slicer favored by FDM players, offering seamless multi-color and single-color printing.
-
![]()
PIXUP FDM Slicer
Phrozen’s in-house slicer, perfectly integrated with ARCO and Chroma Kit, optimizing your printing experience.
-
![]()
Klipper System
Powered by the popular Klipper firmware trusted by advanced makers, ARCO
gives you full access to open settings, letting you push performance to the
limit.*Change settings carefully to avoid mistakes that might cause the printer to work incorrectly.
-
![]()
Complete Support
Our video tutorials and expert support team are here to guide you at every step, so you can print with confidence right out of the box.
Media Spotlight
ARCO Specifications
- Technology: FDM (Fused Deposition Modeling)
- Structure: CoreXY Fixed Print Bed Structure
- Color Support: Multi-color compatible (requires Chroma Kit)
- Print Volume: 30.0 × 30.0 × 30.0 cm
- Max Print Speed / Acceleration: 1,000 mm/s; Max 40,000 mm/s² acceleration
- Max Flow Rate: 50 mm³/s (CHT nozzle)
- Print Bed Material: High-temperature dual-sided textured PEI print bed
- Max Heated Bed Temperature: 110 °C / 230 °F
- Software: PIXUP FDM Slicer / Orca Slicer, Wi-Fi / USB file transfer, .gcode format
Compare to Other Brands
Item | ARCO | P Printer | A Printer | K Printer |
Structure | CoreXY + Flying Gantry | CoreXY +Fixed Gantry | Gantry | CoreXY +Fixed Gantry |
Bed Movement | Fixed Bed More Stable! | Moving Bed | Moving Bed | Moving Bed |
Print Volume (L x W x H) | 30 x 30 x 30 cm Bigger! | 25.6 x 25.6 x 25.6 cm | 25.6 x 25.6 x 25.6 cm | 35 x 35 x 35 cm |
Max Print Speed | 1000 mm/s Faster! | 500 mm/s | 500 mm/s | 500 mm/s |
Max Flow Rate | 50 mm³/s Faster! | 32 mm³/s | 32 mm³/s | 40 mm³/s |
Max Nozzle Temperature | 300 ℃ | 300 ℃ | 300 ℃ | 300 ℃ |
Max Heated Bed Temperature | 110 ℃ | 100 ℃ | 100 ℃ | 120 ℃ |
Max Chamber Temperature | 35 ℃ - 55 ℃ | 60 ℃ | ||
Enclosed Chamber | Add-on | |||
Print Bed Material | PEI Flexible Steel Plate | PEI Flexible Steel Plate | PEI Flexible Steel Plate | PEI Flexible Steel Plate |
Calibration | Temperature | Motor Noise Reduction | Motor Noise Reduction | Temperature
|
項目 | ARCO | P 機台 | A 機台 | K 機台 |
架構類型 | Core XY + 飛行橫樑 | Core XY + 固定橫樑 | 龍門 | Core XY + 固定橫樑 |
載台做動 | 固定載台 | 載台Z軸移動 | 載台X軸移動 | 載台Z軸移動 |
列印體積 | 300 mm³ | 256 mm³ | 256 mm³ | 350 mm³ |
最大列印速度 | 1000 mm/s | 500 mm/s | 500 mm/s | 500 mm/s |
最大流速 | 50 mm³/s | 32 mm³/s | 32 mm³/s | 40 mm³/s |
最高噴頭溫度 | 110℃ | 100℃ | 100℃ | 120℃ |
最高腔體溫度 | 60℃ | |||
封閉機箱 | ||||
列印床材質 | 高溫列印面板 | 紋理 PEI 彈性鋼板 | 紋理 PEI 彈性鋼板 | 彈性磁吸列印板 |
列印校正 | 溫度震動 | 電機降噪 | 電機降噪 | 溫度 |
項目 | ARCO |
架構類型 | Core XY + 飛行橫樑 |
載台做動 | 固定載台 |
列印體積 | 300 mm³ |
最大列印速度 | 1000 mm/s |
最大流速 | 50 mm³/s |
最高噴頭溫度 | 110℃ |
最高腔體溫度 | |
封閉機箱 | |
列印床材質 | 高溫列印面板 |
列印校正 | 溫度震動 |
項目 | P 機台 |
架構類型 | Core XY + 固定橫樑 |
載台做動 | 載台Z軸移動 |
列印體積 | 256 mm³ |
最大列印速度 | 500 mm/s |
最大流速 | 32 mm³/s |
最高噴頭溫度 | 100℃ |
最高腔體溫度 | |
封閉機箱 | |
列印床材質 | 紋理 PEI 彈性鋼板 |
列印校正 | 電機降噪 |
項目 | A 機台 |
架構類型 | 龍門 |
載台做動 | 載台X軸移動 |
列印體積 | 256 mm³ |
最大列印速度 | 500 mm/s |
最大流速 | 32 mm³/s |
最高噴頭溫度 | 100℃ |
最高腔體溫度 | |
封閉機箱 | |
列印床材質 | 紋理 PEI 彈性鋼板 |
列印校正 | 電機降噪 |
項目 | K 機台 |
架構類型 | Core XY + 固定橫樑 |
載台做動 | 載台Z軸移動 |
列印體積 | 350 mm³ |
最大列印速度 | 500 mm/s |
最大流速 | 40 mm³/s |
最高噴頭溫度 | 120℃ |
最高腔體溫度 | 60℃ |
封閉機箱 | |
列印床材質 | 彈性磁吸列印板 |
列印校正 | 溫度 |
